Base class providing all the basic funtionalities of a Renderer. More...
#include <RendererAbstract.hpp>
Public Member Functions | |
| RendererAbstract () | |
| RendererAbstract & | operator= (const RendererAbstract &other) |
| virtual const RenderQueue * | render (const RenderQueue *in_render_queue, Camera *camera, real frame_clock)=0 |
| Takes as input the render queue to render and returns a possibly filtered render queue for further processing. | |
| virtual const Framebuffer * | framebuffer () const =0 |
| The Framebuffer on which the rendering is performed. | |
| virtual Framebuffer * | framebuffer ()=0 |
| The Framebuffer on which the rendering is performed. | |
| void | dispatchOnRendererStarted () |
| Dispatches the onRendererStarted() event to the registered RenderEventCallback objects. | |
| void | dispatchOnRendererFinished () |
| Dispatches the onRendererFinished() event to the registered RenderEventCallback objects. | |
| Collection< RenderEventCallback > * | onFinishedCallbacks () |
| Returns the list of RenderEventCallback objects registered to onRendererFinished() event notification. | |
| const Collection < RenderEventCallback > * | onFinishedCallbacks () const |
| Returns the list of RenderEventCallback objects registered to onRendererFinished() event notification. | |
| Collection< RenderEventCallback > * | onStartedCallbacks () |
| Returns the list of RenderEventCallback objects registered to onRendererStarted() event notification. | |
| const Collection < RenderEventCallback > * | onStartedCallbacks () const |
| Returns the list of RenderEventCallback objects registered to onRendererStarted() event notification. | |
| unsigned long | renderTick () const |
| The current render tick number, equivalent to the number or calls made to the render() method. | |
| void | incrementRenderTick () |
| Increments the rendering tick count. | |
| void | setClearFlags (EClearFlags clear_flags) |
| The clear flags used to clear the viewport. | |
| EClearFlags | clearFlags () const |
| The clear flags used to clear the viewport. | |
| void | setEnableMask (unsigned int mask) |
| Enable mask used to enable/disable the rendering of matching Actors. | |
| unsigned int | enableMask () const |
| Enable mask used to enable/disable the rendering of matching Actors. | |
| void | setFrameClock (real t) |
| The current rendring frame time. | |
| real | frameClock () const |
| The current rendring frame time. | |
Protected Attributes | |
| ref< Collection < RenderEventCallback > > | mOnFinishedCallbacks |
| ref< Collection < RenderEventCallback > > | mOnStartedCallbacks |
| unsigned long | mRenderTick |
| unsigned int | mEnableMask |
| EClearFlags | mClearFlags |
| real | mFrameClock |
Detailed Description
Base class providing all the basic funtionalities of a Renderer.
Definition at line 51 of file RendererAbstract.hpp.
Constructor & Destructor Documentation
| vl::RendererAbstract::RendererAbstract | ( | ) | [inline] |
Definition at line 56 of file RendererAbstract.hpp.
References vl::CF_CLEAR_COLOR_DEPTH, and VL_DEBUG_SET_OBJECT_NAME.
Member Function Documentation
| RendererAbstract& vl::RendererAbstract::operator= | ( | const RendererAbstract & | other ) | [inline] |
Definition at line 67 of file RendererAbstract.hpp.
References mClearFlags, mEnableMask, mOnFinishedCallbacks, and mOnStartedCallbacks.
| virtual const RenderQueue* vl::RendererAbstract::render | ( | const RenderQueue * | in_render_queue, |
| Camera * | camera, | ||
| real | frame_clock | ||
| ) | [pure virtual] |
Takes as input the render queue to render and returns a possibly filtered render queue for further processing.
Renderer's implementation of this function always returns in_render_queue.
Implemented in vl::EdgeRenderer, vl::OcclusionCullRenderer, and vl::Renderer.
| virtual const Framebuffer* vl::RendererAbstract::framebuffer | ( | ) | const [pure virtual] |
The Framebuffer on which the rendering is performed.
Implemented in vl::OcclusionCullRenderer, and vl::Renderer.
| virtual Framebuffer* vl::RendererAbstract::framebuffer | ( | ) | [pure virtual] |
The Framebuffer on which the rendering is performed.
Implemented in vl::OcclusionCullRenderer, and vl::Renderer.
| void vl::RendererAbstract::dispatchOnRendererStarted | ( | ) | [inline] |
Dispatches the onRendererStarted() event to the registered RenderEventCallback objects.
Definition at line 89 of file RendererAbstract.hpp.
References vl::Collection< T >::eraseAt(), and vl::Collection< T >::size().
| void vl::RendererAbstract::dispatchOnRendererFinished | ( | ) | [inline] |
Dispatches the onRendererFinished() event to the registered RenderEventCallback objects.
Definition at line 103 of file RendererAbstract.hpp.
References vl::Collection< T >::eraseAt(), and vl::Collection< T >::size().
| Collection<RenderEventCallback>* vl::RendererAbstract::onFinishedCallbacks | ( | ) | [inline] |
Returns the list of RenderEventCallback objects registered to onRendererFinished() event notification.
Definition at line 117 of file RendererAbstract.hpp.
| const Collection<RenderEventCallback>* vl::RendererAbstract::onFinishedCallbacks | ( | ) | const [inline] |
Returns the list of RenderEventCallback objects registered to onRendererFinished() event notification.
Definition at line 120 of file RendererAbstract.hpp.
| Collection<RenderEventCallback>* vl::RendererAbstract::onStartedCallbacks | ( | ) | [inline] |
Returns the list of RenderEventCallback objects registered to onRendererStarted() event notification.
Definition at line 123 of file RendererAbstract.hpp.
| const Collection<RenderEventCallback>* vl::RendererAbstract::onStartedCallbacks | ( | ) | const [inline] |
Returns the list of RenderEventCallback objects registered to onRendererStarted() event notification.
Definition at line 126 of file RendererAbstract.hpp.
| unsigned long vl::RendererAbstract::renderTick | ( | ) | const [inline] |
The current render tick number, equivalent to the number or calls made to the render() method.
Definition at line 129 of file RendererAbstract.hpp.
| void vl::RendererAbstract::incrementRenderTick | ( | ) | [inline] |
Increments the rendering tick count.
Definition at line 132 of file RendererAbstract.hpp.
| void vl::RendererAbstract::setClearFlags | ( | EClearFlags | clear_flags ) | [inline] |
The clear flags used to clear the viewport.
Definition at line 135 of file RendererAbstract.hpp.
| EClearFlags vl::RendererAbstract::clearFlags | ( | ) | const [inline] |
The clear flags used to clear the viewport.
Definition at line 138 of file RendererAbstract.hpp.
| void vl::RendererAbstract::setEnableMask | ( | unsigned int | mask ) | [inline] |
Enable mask used to enable/disable the rendering of matching Actors.
Definition at line 141 of file RendererAbstract.hpp.
| unsigned int vl::RendererAbstract::enableMask | ( | ) | const [inline] |
Enable mask used to enable/disable the rendering of matching Actors.
Definition at line 144 of file RendererAbstract.hpp.
Referenced by vl::Renderer::render(), vl::OcclusionCullRenderer::render(), vl::EdgeRenderer::render(), and vl::OcclusionCullRenderer::render_pass2().
| void vl::RendererAbstract::setFrameClock | ( | real | t ) | [inline] |
The current rendring frame time.
vl::Renderer passes this value to ActorEventCallback::onActorRenderStarted()
Definition at line 147 of file RendererAbstract.hpp.
| real vl::RendererAbstract::frameClock | ( | ) | const [inline] |
The current rendring frame time.
vl::Renderer passes this value to ActorEventCallback::onActorRenderStarted()
Definition at line 150 of file RendererAbstract.hpp.
Member Data Documentation
ref< Collection<RenderEventCallback> > vl::RendererAbstract::mOnFinishedCallbacks [protected] |
Definition at line 153 of file RendererAbstract.hpp.
Referenced by operator=().
ref< Collection<RenderEventCallback> > vl::RendererAbstract::mOnStartedCallbacks [protected] |
Definition at line 154 of file RendererAbstract.hpp.
Referenced by operator=().
unsigned long vl::RendererAbstract::mRenderTick [protected] |
Definition at line 155 of file RendererAbstract.hpp.
unsigned int vl::RendererAbstract::mEnableMask [protected] |
Definition at line 156 of file RendererAbstract.hpp.
Referenced by operator=().
EClearFlags vl::RendererAbstract::mClearFlags [protected] |
Definition at line 157 of file RendererAbstract.hpp.
Referenced by operator=().
real vl::RendererAbstract::mFrameClock [protected] |
Definition at line 158 of file RendererAbstract.hpp.
The documentation for this class was generated from the following file:
- /home/master/UCL/VisualizationLibrary/src/vlGraphics/RendererAbstract.hpp
