vl::Object Class Reference

The base class for all the reference counted objects. More...

#include <Object.hpp>

Inheritance diagram for vl::Object:

Public Member Functions
	Object ()
	Constructor. More...
	Object (const Object &other)
	Copy constructor: copies the name, ref count mutex and user data. More...
Object &	operator= (const Object &other)
	Copy operator: copies the object's name, ref count mutex and user data. More...
const std::string &	objectName () const
	The name of the object, by default set to the object's class name. More...
void	setObjectName (const char *name)
	The name of the object, by default set to the object's class name in debug builds. More...
void	setObjectName (const std::string &name)
	The name of the object, by default set to the object's class name in debug builds. More...
void	setRefCountMutex (IMutex *mutex)
	The mutex used to protect the reference counting of an Object across multiple threads. More...
IMutex *	refCountMutex ()
	The mutex used to protect the reference counting of an Object across multiple threads. More...
const IMutex *	refCountMutex () const
	The mutex used to protect the reference counting of an Object across multiple threads. More...
int	referenceCount () const
	Returns the number of references of an object. More...
void	incReference () const
	Increments the reference count of an object. More...
void	decReference ()
	Decrements the reference count of an object and deletes it if both automaticDelete() is true the count reaches 0. More...
void	setAutomaticDelete (bool autodel_on)
	If set to true the Object is deleted when its reference count reaches 0. More...
bool	automaticDelete () const
	If set to true the Object is deleted when its reference count reaches 0. More...
template<class T >
T *	as ()
	Casts an Object to the specified class. More...
template<class T >
const T *	as () const
	Casts an Object to the specified class. More...

Protected Member Functions
virtual	~Object ()

Protected Attributes
std::string	mObjectName
IMutex *	mRefCountMutex
int	mReferenceCount
bool	mAutomaticDelete

Detailed Description

The base class for all the reference counted objects.

See also vl::ref.

Definition at line 158 of file Object.hpp.

Constructor & Destructor Documentation

Object() [1/2]

vl::Object::Object ( )

inline

Constructor.

Definition at line 164 of file Object.hpp.

References NULL.

Object() [2/2]

vl::Object::Object ( const Object &  other )

inline

Copy constructor: copies the name, ref count mutex and user data.

Definition at line 181 of file Object.hpp.

References mObjectName, and mRefCountMutex.

~Object()

Object::~Object ( )

protectedvirtual

Definition at line 45 of file Object.cpp.

References automaticDelete(), vl::Log::bug(), mObjectName, and mReferenceCount.

Member Function Documentation

as() [1/2]

template<class T >

T* vl::Object::as ( )

inline

Casts an Object to the specified class.

Definition at line 282 of file Object.hpp.

Referenced by vl::expandResourceDatabase(), vlX::VLXClassWrapper_Array::export_ArrayT(), vlX::VLXClassWrapper_ActorEventCallback::exportActorEventCallback(), vlX::VLXClassWrapper_DrawCall::exportDrawCall(), vlX::VLXClassWrapper_LODEvaluator::exportLODEvaluator(), vlX::VLXClassWrapper_Geometry::exportVLX(), vlX::VLXClassWrapper_DrawCall::exportVLX(), vlX::VLXClassWrapper_PatchParameter::exportVLX(), vlX::VLXClassWrapper_ResourceDatabase::exportVLX(), vlX::VLXClassWrapper_Uniform::exportVLX(), vlX::VLXClassWrapper_Shader::exportVLX(), vlX::VLXClassWrapper_LODEvaluator::exportVLX(), vlX::VLXClassWrapper_Effect::exportVLX(), vlX::VLXClassWrapper_Actor::exportVLX(), vlX::VLXClassWrapper_Camera::exportVLX(), vlX::VLXClassWrapper_Viewport::exportVLX(), vlX::VLXClassWrapper_Transform::exportVLX(), vlX::VLXClassWrapper_Light::exportVLX(), vlX::VLXClassWrapper_ClipPlane::exportVLX(), vlX::VLXClassWrapper_GLSLProgram::exportVLX(), vlX::VLXClassWrapper_GLSLShader::exportVLX(), vlX::VLXClassWrapper_VertexAttrib::exportVLX(), vlX::VLXClassWrapper_Color::exportVLX(), vlX::VLXClassWrapper_SecondaryColor::exportVLX(), vlX::VLXClassWrapper_Normal::exportVLX(), vlX::VLXClassWrapper_Material::exportVLX(), vlX::VLXClassWrapper_ActorEventCallback::exportVLX(), vlX::VLXClassWrapper_Texture::exportVLX(), vlX::VLXClassWrapper_TexParameter::exportVLX(), vlX::VLXClassWrapper_TextureImageUnit::exportVLX(), vl::Geometry::flipNormals(), vlX::VLXClassWrapper_ActorEventCallback::importActorEventCallback(), vlX::VLXClassWrapper_DrawCall::importDrawCall(), vlX::VLXClassWrapper_GLSLProgram::importGLSLProgram(), vlX::VLXClassWrapper_LODEvaluator::importLODEvaluator(), vlX::VLXClassWrapper_Transform::importTransform(), vl::Terrain::init(), vl::Applet::initialize(), vl::DaeLoader::load(), vlX::loadVLB(), vlX::loadVLT(), vl::DepthSortCallback::onActorRenderStarted(), vlX::VLXValue::setArray(), vl::Geometry::shrinkDrawCalls(), and vl::Geometry::sortVertices().

as() [2/2]

template<class T >

const T* vl::Object::as ( ) const

inline

Casts an Object to the specified class.

Definition at line 286 of file Object.hpp.

automaticDelete()

bool vl::Object::automaticDelete ( ) const

inline

If set to true the Object is deleted when its reference count reaches 0.

Definition at line 278 of file Object.hpp.

Referenced by ~Object().

decReference()

void vl::Object::decReference ( )

inline

Decrements the reference count of an object and deletes it if both automaticDelete() is true the count reaches 0.

Definition at line 255 of file Object.hpp.

References vl::IMutex::lock(), vl::IMutex::unlock(), and VL_CHECK.

incReference()

void vl::Object::incReference ( ) const

inline

Increments the reference count of an object.

Definition at line 241 of file Object.hpp.

Referenced by vlX::VLXValue::setArrayInteger(), vlX::VLXValue::setArrayReal(), vlX::VLXValue::setList(), vlX::VLXValue::setRawtextBlock(), and vlX::VLXValue::setStructure().

objectName()

const std::string& vl::Object::objectName ( ) const

inline

The name of the object, by default set to the object's class name.

Definition at line 217 of file Object.hpp.

Referenced by vl::TextureImageUnit::apply(), vl::GLSLShader::compile(), vl::Image::convertFormat(), vl::Image::convertType(), vlX::VLXClassWrapper_Actor::exportActor(), vlX::VLXClassWrapper_Camera::exportCamera(), vlX::VLXClassWrapper_DrawCall::exportDrawCallBase(), vlX::VLXClassWrapper_Effect::exportEffect(), vlX::VLXClassWrapper_GLSLProgram::exportGLSLProgram(), vlX::VLXClassWrapper_Light::exportLight(), vlX::VLXClassWrapper_Material::exportMaterial(), vlX::VLXClassWrapper_Renderable::exportRenderable(), vlX::VLXClassWrapper_ResourceDatabase::exportResourceDatabase(), vlX::VLXClassWrapper_Shader::exportShader(), vlX::VLXClassWrapper_Texture::exportTexture(), vlX::VLXClassWrapper_Transform::exportTransform(), vlX::VLXClassWrapper_VertexAttrib::exportVertexAttrib(), vlX::VLXClassWrapper_Viewport::exportViewport(), vl::GLSLProgram::infoLog(), vl::MorphingCallback::init(), vl::GLSLProgram::linkProgram(), vl::DaeLoader::load(), vl::ObjLoader::loadOBJ(), vl::Image::print(), vl::GLSLProgram::programBinary(), vl::Renderer::renderRaw(), and vl::OpenGLContext::useGLSLProgram().

operator=()

Object& vl::Object::operator= ( const Object &  other )

inline

Copy operator: copies the object's name, ref count mutex and user data.

Definition at line 201 of file Object.hpp.

References mObjectName, and mRefCountMutex.

Referenced by vlX::VLXValue::~VLXValue().

refCountMutex() [1/2]

IMutex* vl::Object::refCountMutex ( )

inline

The mutex used to protect the reference counting of an Object across multiple threads.

Definition at line 229 of file Object.hpp.

refCountMutex() [2/2]

const IMutex* vl::Object::refCountMutex ( ) const

inline

The mutex used to protect the reference counting of an Object across multiple threads.

Definition at line 232 of file Object.hpp.

referenceCount()

int vl::Object::referenceCount ( ) const

inline

Returns the number of references of an object.

Definition at line 235 of file Object.hpp.

setAutomaticDelete()

void vl::Object::setAutomaticDelete ( bool  autodel_on )

inline

If set to true the Object is deleted when its reference count reaches 0.

Definition at line 275 of file Object.hpp.

Referenced by vl::ActorTreeAbstract::ActorTreeAbstract(), vlMFC::MDIWindow::MDIWindow(), vlMFC::MFCWindow::MFCWindow(), vlQt4::Qt4Widget::Qt4Widget(), vlQt5::Qt5Widget::Qt5Widget(), vlQt6::Qt6Widget::Qt6Widget(), and vl::VectorGraphics::VectorGraphics().

setObjectName() [1/2]

void vl::Object::setObjectName ( const char *  name )

inline

The name of the object, by default set to the object's class name in debug builds.

Definition at line 220 of file Object.hpp.

Referenced by vl::Image::convertFormat(), vl::Image::convertType(), vl::Texture::createTexture(), vl::DaeLoader::generateGeometry(), vl::Image::Image(), vlX::VLXClassWrapper_Actor::importActor(), vlX::VLXClassWrapper_Camera::importCamera(), vlX::VLXClassWrapper_DrawCall::importDrawCall(), vlX::VLXClassWrapper_Effect::importEffect(), vlX::VLXClassWrapper_GLSLProgram::importGLSLProgram(), vlX::VLXClassWrapper_Light::importLight(), vlX::VLXClassWrapper_Material::importMaterial(), vlX::VLXClassWrapper_Renderable::importRenderable(), vlX::VLXClassWrapper_ResourceDatabase::importResourceDatabase(), vlX::VLXClassWrapper_Shader::importShader(), vlX::VLXClassWrapper_Texture::importTexture(), vlX::VLXClassWrapper_Transform::importTransform(), vlX::VLXClassWrapper_VertexAttrib::importVertexAttrib(), vlX::VLXClassWrapper_Viewport::importViewport(), vl::DaeLoader::load(), vl::load3DS(), vl::loadAC3D(), vl::loadBMP(), vl::loadDDS(), vl::loadDICOM(), vl::loadImage(), vl::loadJPG(), vl::ObjLoader::loadOBJ(), vl::loadPNG(), vl::loadTGA(), vl::makeBox(), vl::makeCapsule(), vl::makeCircle(), vl::makeCone(), vl::makeCylinder(), vl::makeGrid(), vl::makeIcosahedron(), vl::makeIcosphere(), vl::makePoints(), vl::makePyramid(), vl::makeTorus(), vl::makeUVSphere(), vl::DaeLoader::parseEffects(), vl::DaeLoader::parseLight(), vl::GLSLShader::setSource(), and vl::DaeLoader::setupLights().

setObjectName() [2/2]

void vl::Object::setObjectName ( const std::string &  name )

inline

The name of the object, by default set to the object's class name in debug builds.

Definition at line 223 of file Object.hpp.

setRefCountMutex()

void vl::Object::setRefCountMutex ( IMutex *  mutex )

inline

The mutex used to protect the reference counting of an Object across multiple threads.

Definition at line 226 of file Object.hpp.

Member Data Documentation

mAutomaticDelete

bool vl::Object::mAutomaticDelete

protected

Definition at line 304 of file Object.hpp.

mObjectName

std::string vl::Object::mObjectName

protected

Definition at line 300 of file Object.hpp.

Referenced by Object(), operator=(), vl::Image::reset(), and ~Object().

mRefCountMutex

IMutex* vl::Object::mRefCountMutex

protected

Definition at line 302 of file Object.hpp.

Referenced by Object(), and operator=().

mReferenceCount

int vl::Object::mReferenceCount

mutableprotected

Definition at line 303 of file Object.hpp.

Referenced by ~Object().

---

The documentation for this class was generated from the following files:

• C:/git/VL/src/vlCore/Object.hpp
• C:/git/VL/src/vlCore/Object.cpp
